ecom-J2KNpro Performing Flue Gas Analyser with Remote Control Module via Radio.

With O₂/CO (H₂ comp.) Longlife sensors (life span higher than 4 years by normal load)
Automatic CO-switch-off and sensor purging (without measurement interruption)
Condensate trap resp. gas cooler incl. electronic condensate monitoring (depending on selected model variant)
Powerfull Lithium-Ion battery
Gas cooler with automatic condensate evacuation
Integral thermal quick-printer
High-value gas sampling probe incl. thermocouple, fixation cone and high-value 3-chamber gas sampling tubing
Status display for indication of basic functions, adjustments and warning messages
Complete in ultra-light, robust aluminium housing
T-Room sensor / T-Room stick (according to request resp. model variant)
Integral soot measurement (application-related covered in standard delivery scope)
Fitted in spacious aluminium-framed transport case with comfort shoulder carrying strap
Calibration certificate – issued after 100% sensors calibration into climatic chamber
Free downloadable PC software

Radio Remote Controller

(Included in standard delivery scope)

High coverage for bridging distances between measurement place (gas opening) and adjustment system (e.g. burner, control panel, etc.)
Incl. thermocouple input, mini USB connector (data transfer to laptop/PC), SD card slot
Backlit foil keypad and high-value colour TFT display
Indication, printout and recording of measurement data
Complete instrument operation command (i. a. manual CO switch-off, start and end of measurements, data processing, …)
Stable data transfer via radio (highest avoidance of interferences, bypass of metal or concrete obstacles, automatic connection, no abrupt disconnection, keeping of all measurement values as well as automatic build-up and restoration of radio connection)

Dimensions

(L x H x W): approx. 450 x 315 x 250 mm resp. 510 x 330 x 250 mm (depending on selected model version)

Weight

Brand: ecom
